Strong Bonding is Our Core Technology
The key to a steel lined rubber bushes is the bond strength between rubber and steel. Weak bonding can lead to separation after use. Our bonding technology is mature and reliable. We use Chemlok adhesive from Lord Corporation, applied evenly by our automatic roller coater, which also cures the glue quickly.
Our automatic rubber injection machine precisely controls temperature, pressure, and injection volume. This ensures the rubber and steel in each bushing remain securely bonded.
For example:
- 2912060R004 for JAC Xingrui vans – OD φ57 mm, ID φ18.05 mm, Height 80.5 mm
- 5802968452 for IVECO vans – OD φ40.2 mm, ID φ16.5 mm, Height 35 mm
Both models use our advanced bonding technology. Our R&D team collaborates with universities to study rubber-to-metal bonding, earning our factory the title of High-Tech Enterprise in Anhui Province.
Honors and Factory Strength
Our company has repeatedly been recognized as a High-Tech Enterprise in Anhui Province and has received the Financial Trustworthy Enterprise award from the People's Bank of China. These honors reflect our credibility and reliable business practices.
- Factory land: 30 mu (~20,000 m² building area)
- Employees: 40 skilled personnel
- Certifications: IATF16949 and ISO9001
- Inspection: 100% product check, third-party inspection welcome
- Warranty: 1 year; damaged goods during shipping are replaced free
- Export-grade packing: PE moisture-proof inner layer, five-layer corrugated carton, fixed on wooden pallets, wrapped with film
Custom Production Based on Drawings or Samples
You provide a drawing or sample, and we produce the steel-lined rubber bushing according to your specifications. Our technical team will discuss your requirements, provide a quote, and develop samples.
- Sample development: 35–40 days
- Mass production: After sample approval and mold fee payment
- Minimum order: 500 pieces; different models can be mixed in one order
- Delivery terms: EXW, FOB, CIF, CFR, DDP
- Payment: RMB, USD, HKD; deposit and balance structured per order type
Key Parameters (Focus: Bonding & Certification)
|
Parameter |
Value |
|
Adhesive |
Chemlok (Lord Corporation) |
|
Bonding Method |
Automatic roller coating |
|
Certification |
IATF16949, ISO9001 |
|
Company Title |
High-Tech Enterprise (Anhui) |
|
Sample Development Time |
35–40 days |
Full Product Parameter Table
|
Product Number |
Size (OD×ID×H) |
Applicable Brand / Model |
|
CT-XMHS |
φ40.3×φ20×68.6 |
Golden Dragon Haishi Series / Joylong / Geely |
|
2912060R004 |
φ57×φ18.05×80.5 |
JAC Xingrui Commercial Vehicle |
|
2912070R004 |
φ50×φ16.05×92.1 |
JAC Xingrui Commercial Vehicle |
|
93808935EC12-A |
φ40.2×φ14.15×35 |
Golden Dragon Haishi Series / Joylong |
|
2912110V6500 |
φ55×φ16.2×80.5 |
JAC Ruifeng Series |
|
2902930LE010 |
φ42×φ16.15×81 |
JAC, GEELY, BYD, Yutong Light Truck Series |
|
2912940LE010 |
φ40×φ16.15×43.7 |
JAC, GEELY, BYD, Yutong Light Truck Series |
|
2912930LE010 |
φ42×φ18.15×81 |
JAC, GEELY, BYD, Yutong Light Truck Series |
|
9900012416 |
φ40×φ16.15×43.7 |
GEELY |
|
5802968452 |
φ40.2×φ16.5×35 |
IVECO VAN |
|
5803116028 |
φ40.5×φ16.5×40 |
IVECO EuroCargo / Daily Series |
|
5803116031 |
φ45×φ16.5×40 |
IVECO EuroCargo / Daily Series |
|
5803251849 |
φ50.5×φ16.5×40 |
IVECO EuroCargo / Daily Series |
|
5803251851 |
φ40×φ16.5×49 |
IVECO EuroCargo / Daily Series |
|
9900137685 |
φ60×φ16.2×40.3 |
Geely VAN |
|
9900137686 |
φ67×φ16.2×77 |
Geely VAN |
|
2912050P3010 |
φ42.5×φ16.5×36.5 |
JAC Pickup |
|
AKFH-9020 |
φ58×φ20.1×96 |
Ankai Bus / Coach |
|
2912-00793 |
φ50×φ14.2×72.3 |
Yutong Bus / Coach |
|
PSHAX-00 |
φ40×φ14.15×74 |
BYD Pickup |
